HI-2003 Edge Conductivity Meter
HI-2003 Edge Conductivity Meter
Varastossa
edge® EC is dedicated to testing Conductivity. Using Hanna's latest technology and design, edge® can be adapted to suit your working method. 2 year manufacturer warranty.
Couldn't load pickup availability
Kuvaus
Kuvaus
edge® EC is dedicated to testing Conductivity. Using Hanna's latest technology and design, edge® can be adapted to suit your working method.
Select from hand held, wall mount or bench top - or switch between them all. edge® is happy any which way. Simply plug in the electrode, then play.
Measurement is simpler, quicker and more accurate than ever.
Results are fast and reliable. Combining high precision technology with the user-friendly dimensions and format of a small digital tablet, edge® is breaking new ground in electrochemistry.
This is a must-have meter for your laboratory.
Cutting-edge design, capacitive touch keypad and an intuitive user interface are just a few of the great attributes that make edge® stand out as the world's first Hybrid meter on the market.
Key features
- 4-ring potentiometric probe - covers all ranges from 0.00µS/cm to 500 mS/cm (absolute EC)
- Accuracy - ±1% of the reading (±0.05µS/cm or 1 digit, whichever is greater)
- Calibration - offset (0 µS/cm) and cell factor calibration, choice of 5 standards
- Auto-ranging or manual range selection
- EC, TDS and Salinity reading modes
- Temperature compensation - automatic, NoTC (absolute)
- GLP data - records date, time, offset, and cell constant value (K)
- Adjustable EC to TDS conversion factor
- Adjustable temperature correction factor
- Capacitive touch keys
- Large 140mm LCD display with clear full text readout
- Digital smart electrodes enable edge to automatically recognise and store sensor type, ID and calibration information - with 3.5mm phono connection
- Programmed for basic and advanced modes
- Log-on demand and interval logging
- PC interface via micro USB
- Data download onto USB stick via standard USB
Tekniset tiedot
Tekniset tiedot
| EC Range | 0.00 to 29.99 µS/cm; 30.0 to 299.9 µS/cm; 300 to 2999 µS/cm; 3.00 to 29.99 mS/cm; 30.0 to 200.0 mS/cm; up to 500.0 mS/cm absolute EC | |
| Resolution | 0.01 µS/cm; 0.1 µS/cm; 1 µS/cm; 0.01 mS/cm; 0.1 mS/cm | |
| Accuracy (@25°C) | ±1% of reading (±0.5 µS/cm or 1 digit, whichever is greater) | |
| Calibration | single cell factor calibration; six standards available: 84µS/cm, 1413 µS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 118.8 mS/cm, one point offset: 0.00 µS/cm | |
| Temperature Coefficient | 0.00 to 6.00%/°C (for EC and TDS only), default value is 1.90%/°C | |
| TDS Range | 0.00 to 14.99 mg/L (ppm); 15.0 to 149.9 mg/L (ppm); 150 to 1499 mg/L (ppm); 1.50 to 14.99 g/L; 15.0 to 100.0 g/L; up to 400.0 g/L absolute TDS using 0.80 conversion factor | |
| Resolution | 0.01 mg/L (ppm); 0.1 mg/L (ppm); 1 (ppm); 0.01 g/L; 0.1 g/L | |
| Accuracy (@25°C) | ±1% of reading (±0.03 ppm or 1 digit, whichever is greater) | |
| Calibration | through EC calibration | |
| TDS Factor | 0.40 to 0.80 (default value is 0.50) | |
| Salinity Range | 0.0 to 400.0 % NaCl; 2.00 to 42.00 PSU; 0.0 to 80.0 g/L | |
| Resolution | 0.1 % NaCl; 0.01 PSU; 0.01 g/L | |
| Accuracy (@25°C) | ±1% of reading | |
| Calibration | PSU and g/L through EC calibration; % NaCl - one point with HI-7037 sea water standard | |
| Temperature Range | -20.0 to 120.0 °C | |
| Resolution | 0.1°C | |
| Accuracy | ±0.5°C | |
| Additional Specifications: | ||
| Probe | HI-763100 digital four-ring conductivity probe with 3.5 mm connector and 1m cable | |
| Logging | up to 1000 (400 for basic mode) records organised in: manual log-on demand (max. 200 logs), manual log-on stability (max. 200 logs), interval logging (max. 600 samples; 100 lots) | |
| Connectivity | 1 USB port for storage; 1 micro USB port for charging and PC connectivity | |
| Environment | 0 to 50°C; RH max 95% non-condensing | |
| Power Supply | 5 VDC adapter (included) | |
| Dimensions | 2020 x 140 x 12 mm | |
| Weight | 250 g |
Electrode HI-763100 included:
| Body Material | PEI | |
| Type | 4-ring | |
| Insulator | glass | |
| Electrodes | Platinum | |
| Range | 0 to 200 mS/cm | |
| Environmental Conditions | -5 to 100°C | |
| Body Length | 120mm | |
| Temperature Sensor | Yes | |
| Amplifier | No | |
| Other | Unique serial ID | |
| Digital | yes | |
| Cable | 1m | |
| Connection | 3.5mm jack |
